Home > LCD Panel
sRGB, wide temperature, 1000cd/m2 ultra-high brightness, WLED backlight, lifespan over 50,000 hours, includes LED driver, 6/8-bit grayscale options, matte surface.
Basic Information
Brightness (cd/m2)
1000
Contrast Ratio
1000:1 (Transmission)
Viewing Angle
89/89/89/89 (Typ.)(CR≥10)
Optical Mode
AHVA, Normally Black, Transmissive
Viewing Direction
Full-view
Response Time
25 (Typ.)(Tr+Td) (ms)
Color Performance
Chromaticity
Wx:0.313; Wy:0.329
Color Numbers
262K/16.7M (6-bit / 6-bit+FRC )
Color Temperature
6485K
Uniformity
1.25/1.43 (Typ./Max.)(5 points)
1931 Color Gamut
NTSC Ratio
73%
sRGB
99%
Adobe RGB
75%
DCI-P3
REC.2020
54%
Remarks
sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)
Signal Electrical
Current Input
500mA (Max.)
Voltage Input
3.3V (Typ.)
Consumption
1.65W (Max.)
Signal System
LVDS (1 ch, 6/8-bit)
Interface Features
Position
---
Type
Connector
Connector Detail
Brand
Model
Amount
Pin Pitch
Pins
Starconn
093G30-B0001A-1
1pcs
1.0 mm
30 pins
Back-light Features
Lamp Type
WLED
Replacement
-
Edge Light type
Lamp Shape
Life Time
50K (Min.) hours
Included in the signal interface
Driver Electrical
with LED Driver
10.0/12.0/15.0V (Min./Typ./Max.)
0.63/0.73A (Typ./Max.)
7.6/8.8W (Typ./Max.)
Product Core Advantage: G121EAN01.2 offers a typical brightness of up to 1000 cd/m², which is 2 to 4 times that of ordinary LCD panels. It can effectively resist environmental light interference and ensure that the content remains clear, sharp and rich in color even under the midday sunlight. Technical Support Advantages: a. High-brightness backlight system: Utilizing high-efficiency WLEDs and custom optical modules, it achieves high brightness while maintaining low power consumption and long lifespan. b. Wide temperature operating capability: An industrial-grade temperature range of -30℃ to 85℃, capable of adapting to sudden changes in outdoor climates from extremely cold to extremely hot. c. Enhance environmental durability: Fully sealed design (optional), high-hardness surface coating, dust-proof, scratch-resistant, resistant to outdoor moisture and corrosion. d. Fast response time: A response speed of 25ms (Typ.) ensures no ghosting in dynamic images, making it suitable for displaying real-time data and videos.
This high-brightness industrial LCD display module has been specially optimized for the following outdoor and special environment applications: 1. Outdoor digital signage and advertising machines: Suitable for use on the exterior walls of shopping malls, bus stops, squares, etc., in strong light environments, ensuring that advertising information is clearly visible. 2. Industrial automation and control terminal: Applied in scenarios such as factory workshops and outdoor workstations, it displays real-time data of equipment and monitoring screens. 3. Ship and aircraft display screens: Meeting the high environmental light and wide temperature operating requirements in cabins, decks and engine rooms. 4. Medical diagnostic equipment (outdoor/vehicle-mounted): Used for mobile medical vehicles, field rescue equipment, etc. It can accurately display images even under direct sunlight. 5. New energy charging station display screen: Designed for all-weather operation outdoors, with high brightness to ensure that the user interface is legible even in direct sunlight. 6. Cockpit display for construction machinery and agricultural machinery: It can stably display key parameters under harsh conditions such as vibration, high and low temperatures, and dust. 7. Outdoor self-service terminals: such as self-service ticket vending machines, inquiry machines, express delivery cabinets, etc., enhance the user experience in outdoor scenarios.
HXD is a professional manufacturer that has been deeply involved in the LCD TFT display industry for 12 years. We focuse on providing you with high-quality custom LCD display solutions and related services. At the core product level, we provide global high-end brands such as AUO, BOE, IVO, CHEIMEI, Innolux, and Sharp to meet the LCD display requirements in different scenarios. We also have our own independent R&D production capacity and can provide supporting accessories such as driver boards, cables, and touch screens that are compatible with LCD panels, achieving "LCD panel + accessories" one-stop supply. With 12 years of accumulated professional technology and experience, HXD not only provides standardized products but also supports OEM & ODM customization services, precisely matching your individualized needs. The service also offers free quotations and free technical document support, providing efficient and high-quality services from demand connection, scheme design to after-sales guarantee, and is committed to becoming a trusted LCD display solution partner for you.
FAQs:
Q1 : Does AUO G121EAN01.2 support touch functionality?
A: AUO G121EAN01.2 itself is without touch design. However, it supports the external connection of capacitive / resistive / infrared touch screens of the corresponding size. If you need a touch design, please feel free to contact us. We also provide touch bonding service and glass bonding service.
Q2: Will the 1000 cd/m² brightness power consumption of G121EAN01.2 be much higher than that of ordinary LCD panels?
A: Although the brightness has significantly increased, G121EAN01.2 adopts an efficient WLED backlight system and optimized driving circuit, and its power consumption is within the reasonable industrial range. The actual power consumption is related to the backlight settings and usage scenarios. We provide various energy-saving accessories. If you need more details, please contact us.
Q3: Will the matte finish treatment affect the clarity and color of the LCD TFT display?
A: The matte finish treatment will slightly reduce the peak contrast (about 5-10%), but its main value lies in eliminating the reflection of ambient light. In outdoor or bright indoor environments, the overall readability is significantly improved compared to the minor contrast loss. It can ensure accurate colors and a soft and pleasant picture.
Q4: The interface is a 30-pin LVDS. Is it compatible with the current mainstream HDMI or DP interfaces?
A: LVDS is a standard interface in the industrial LCD display field, known for its high resistance to interference and stable long-distance transmission. It does not directly support HDMI/DP and other consumer-level interfaces, but it can be easily connected to HDMI, DP, VGA, or even the RGB interface of embedded systems through the LVDS conversion board/controller board we provide. If you need more details, please contact us.
