G190ETN01.001

DCI-P3, sRGB, White LED Backlight, Front-Mount Terminals, Matte Surface, 85% NTSC.

19-Inch High-Performance Industrial TFT LCD Display – AUO G190ETN01.001 for Indoor Industry

AUO G190ETN01.001 is a cutting-edge 19-inch TFT LCD panel designed for professional applications that require high-quality display performance under varied lighting conditions. With a resolution of 1280x1024 pixels (SXGA) and a brightness of 350 nits, the LCD display excels in delivering clear and vibrant images in moderately lit environments, making it a perfect choice for applications such as medical equipment, industrial controls, and digital signage.

Key Features & Benefits:

• High Resolution & Clarity: With 1280x1024 resolution and a pixel density of 86 PPI, AUO G190ETN01.001 LCD panel offers sharp text and detailed images, ensuring clear visual communication and optimal readability for users.

• Wide Color Gamut: With 92% DCI-P3 color coverage, this panel provides rich, vivid colors, perfect for color-critical applications like digital signage and high-quality imaging displays.

• Compact & Space-Efficient Design: With a slim profile, AUO G190ETN01.001 easily fits into tight spaces, making it a great option for mounting in compact kiosks, terminals, or equipment consoles.

AUO G190ETN01.001 is the ideal choice for industries that need reliable, high-performance LCD displays for daily operations in environments that require consistent, high-quality visual output.

AUO G190ETN01.001 Basic Parameters

Brand	AUO	Model	G190ETN01.001
Diagonal Size	19.0 inch	Type	a-Si TFT-LCD, LCM
Resolution	1280(RGB)x1024, SXGA 86PPI	Pixel Format	RGB Vertical Stripe
Active Area	376.32(W)x301.056(H) mm	Visual Area	380.0(W)x305.08(H) mm
Outline Dimension	396(H)x324(V) x11.7(D) mm	Surface Treatment	Matte
Brightness	350 cd/m² (Typ.)	Contrast Ratio	1000:1(Typ.)(TM)
Visual Direction	---	Response Time	3.6/1.4 (Typ.)(Tr/Td)
Viewing Angle	85/85/80/80(Typ.)(CR≥10)	Operating Mode	TN, Normally White, Transmissive
Display Color	16.7M, 92% DCI-P3	Backlight	WLED [13S4P],30K hours, Without LED Driver
Weight	1.80Kgs (Typ.)	Application	Industrial Control
Operating Frequency	60Hz	Touch Function	No
Interface	LVDS (2 ch,8-bit), 30 pins, Connector
Power Supply	5.0V(Typ.)
Environment Temperature	Operating Temperature:0~50℃; Storage Temperature:-20~60℃

AUO G190ETN01.001 LCD Panel Application Devices & Benefits

AUO G190ETN01.001 offers exceptional visual clarity, durability, and versatile compatibility, making it the perfect solution for your industrial, medical, or commercial display needs. 19-inch AUO G190ETN01.001 LCD panel is designed to be used in a variety of industrial and commercial applications, providing solutions across several sectors:

1. Industrial Control Systems

Terminals: Operator panels, control stations, and manufacturing dashboards etc.

Benefits: The high brightness and clarity of AUO G190ETN01.001 allow operators to clearly see data and monitor equipment performance even in moderately bright environments. With a long operational lifespan, this panel ensures reliability in continuous, 24/7 industrial environments.

2. Medical Devices

Terminals: Medical imaging systems, diagnostic monitors, and patient monitoring systems etc.

Benefits: The sharp resolution and color accuracy help healthcare professionals make informed decisions based on accurate, readable visuals. The 350 nit brightness ensures AUO G190ETN01.001 is visible under different lighting conditions commonly found in hospitals and medical facilities.

3. Digital Signage and Kiosks

Terminals: Information kiosks, advertising displays, and interactive screens etc.

Benefits: The vibrant display, with 92% DCI-P3 color coverage, provides eye-catching, detailed visuals for marketing purposes or user interaction, making AUO G190ETN01.001 ideal for indoor kiosks in commercial areas.

4. POS (Point-of-Sale) Systems

Terminals: Retail point-of-sale displays and self-service terminals etc.

Benefits: AUO G190ETN01.001 clarity and bright visuals ensure that products and prices are clearly visible to customers, even in high-traffic retail environments.

5. Transportation Systems

Terminals: Transport terminal displays, ticketing systems, and wayfinding kiosks etc.

Benefits: High visibility under indoor lighting conditions ensures passengers can easily view information while on the move, improving the overall user experience in busy airports, train stations, and bus terminals.

Looking for a reliable 19-inch industrial LCD display for your application?

Zhengzhou Hengxinda Technology is a China Supplier, offering industrial TFT LCD displays and relevant accessories including LCD touch screen, LCD control board, light sensor cable, adapter plate and custom cable etc. We understand that every application is unique, and we are here to assist you in selecting the right TFT LCD display for your specific requirements. Whether you're looking for a sunlight readable industrial LCD panel, rugged LCD display monitor, or high-performance HMI panel, we can guide you through the process.

Get in touch with us now for personalized support and to request a detailed quote. We provide:

• Custom LCD display solutions tailored to your needs

• Reliable, quick shipping to meet your project deadlines

• Samples to ensure the perfect fit for your applications

• Touch screen bonding service and glass bonding service

• One-stop shopping experience

FAQ:

Q1: What is the brightness of the AUO G190ETN01.001 display?

A1: AUO G190ETN01.001 has a brightness of 350 nits, which is perfect for moderately lit indoor environments such as industrial control panels and medical equipment displays.

Q2: Can I use AUO G190ETN01.001 outdoors?

A2: AUO G190ETN01.001 is not designed for direct sunlight exposure. If you need a high brightness LCD display for outdoor use in bright sunlight, we recommend looking into our high brightness outdoor displays with higher brightness ratings, such as 800 nits or more.

Q3: Is AUO G190ETN01.001 suitable for medical use?

A3: Yes, AUO G190ETN01.001 is an excellent choice for medical devices such as diagnostic and monitoring systems, providing clear and reliable visuals under typical hospital lighting conditions.

Q4: What is the operating temperature range of the AUO G190ETN01.001?

A4: This display operates in a temperature range of -20°C to 60°C, making it suitable for industrial and commercial environments with varying temperature conditions.

Q5: Can I get a sample of this product before placing a bulk order?

A5: Yes, we offer sample requests to ensure the product meets your specifications and requirements. Please contact us for more details.

Q6: What are the interface options for G190ETN01.001?

A6: AUO G190ETN01.001 uses an LVDS interface and supports 60Hz operation, making it easy to integrate into various industrial and commercial systems. If you need other interfaces, we can also customize according to your needs.

Q7: Do you offer customization for LCD displays?

A7: Yes, we offer customization options for our LCD displays, including specific interface requirements and configurations tailored to your project needs. Contact us to discuss further.

Q8: What is the lead time for AUO G190ETN01.001?

A8: The typical lead time is between 1-3 weeks depending on your order volume. For larger or custom orders, please reach out for a more accurate lead time.
