Wide Temperature, Ultra-high Brightness, White LED Backlight, Lifespan exceeding 50,000 hours, Front-mounted Terminals, and Matte surface.
Brand
AUO
Type
a-Si TFT-LCD
Model
G190ETN01.601
Surface Finish
Hard coating (2H)
Size (inch)
19
Pixel Layout
RGB Vertical Strip
Outline Dimension (WxHxD mm)
396(W)×324.3(H)×15.79(D)
Operating Mode
TN
Active Area (WxH mm)
376.32(W)x301.056(H)
Backlight Type
WLED
Viewing Angle
85/85/80/80
Interface
LVDS, 30 pins
Resolution
1280x1024 (SXGA)
Response Time
10 (Typ.)(Tr/Td) ms
Brightness (cd/m²)
1600
Dispay Colors
16.7M, 70%NTSC
Contrast Ratio
1000:1
Operating Temperature (°C )
-30~ 70
Operating Voltage
5V
Storage Temperature (°C )
-30 ~ 70
Operating Frequency
60Hz
Weight
1.8Kgs
Application
Industrial Control, Outdoor High Brightness Environment
✅12 Years of LCD Supply Chain Expertise
Since 2013, we’ve specialized in LCD distribution and customization, representing 7 top brands like AUO, TIANMA, and BOE. With over 100,000 panels in stock and 24/7 global shipping, our supply chain is rock-solid and reliable.
✅Backed by 7 International Certifications
ISO 9001/13485/14001, CE, RoHS, and IATF 16949 (in progress) — every shipment includes original test reports, ensuring zero export hurdles.
✅One-Stop Engineering Customization
Our 15-member expert team delivers prototypes in 7 days and mass production in 30. We support IP67 protection, -40~85℃ extreme temps, MIL-STD shock resistance, and sunlight-readable displays.
✅Proven by 3000+ Global Clients
Serving industry leaders like CRRC, Philips Healthcare, and BYD Automotive, we’ve delivered over 3 million flawless panels with zero returns and 95+ NPS satisfaction.
📩Request Full Free Quotation & Custom Solution Now → Email & WhatsApp & Wechat
1. What are the core brightness specifications for the AUO G190ETN01.601? A: With a peak brightness of 1600 nits and wide viewing angle technology, it delivers clear, glare-free images under bright sunlight. This makes it ideal for outdoor applications such as outdoor advertising displays, in-vehicle displays, and outdoor surveillance terminals.
2. What are the resolution and aspect ratio of this 19-inch LCD panel? A: Resolution: 1280×1024 (SXGA), Aspect Ratio: 4:3. Its high pixel density delivers sharp text and image display, making it suitable for applications requiring display precision like industrial control systems and medical equipment.
3. What interfaces does the product support? A: Standard LVDS interface. Optional VGA/HDMI adapter boards available upon request. Compatible with mainstream industrial control hosts and embedded devices. Plug-and-play functionality requires no additional debugging.
4. What are the operating temperature range and lifespan? A: Operating temperature: -30°C to 70°C. Resistant to extreme temperatures and electromagnetic interference, suitable for harsh industrial environments. MTBF ≥ 50,000 hours ensures high stability.
5. Does the company offer customization services? A: Supports OEM/ODM customization. Adjustable brightness (800-2000 nits), protection rating (IP65), interface types, etc., to meet specialized requirements for automotive, outdoor terminals, and other scenarios.
6. What quality certifications does the product hold? A: Certified with CE/RoHS. Features AUO factory-grade A-panel displays, each undergoing 72-hour burn-in testing. Includes 1-year full-unit warranty + lifetime technical support. Free repairs for non-human-induced damage.
7. Are bulk purchase discounts available? A: Minimum order quantity (MOQ) is 2 units. Volume discounts apply for orders ≥50 units, with higher discounts for larger quantities. Contact us for specific pricing.
8. How can I get technical support for installation and usage issues? A: We provide 24/7 online technical support (via email/phone/video). Detailed installation manuals and driver documentation are included. Engineers can remotely assist with installation and debugging issues.
9. Besides the display screen, do you provide matching accessories ? A: We offer one-stop solutions for matching accessories including controller boards, touchscreens, and optical cables. No need for separate procurement, reducing integration costs and ensuring product compatibility.
