G215HCJ-LH1

G215HCJ-LH1

Download PDF Send Message

Basic Parameters

Panel Brand	Innolux	panel model	G215HCJ-LH1
Panel size	21.5-inch	panel type	a-Si TFT-LCD, LCD Module
resolution ratio	1920(RGB)x1080,FHD,102PPI	pixel layout	RGB vertical stripes
display area	476.6(W)x268.1(H) mm	Appearance size	495.6(W)x292.2(H)x24.55(D) mm
visible size	479.84(W)x271.31(H) mm	surface treatment	Hard coating(2H)
Brightness (cd/m²)	1400 (Typ.)	contrast	1000:1(Typ.) [Transmission]
best angle	full-view	optical mode	AHVA, normally black display, transmissive
visual Angle	89/89/89/89 (Typ.) (CR≥10)	response speed	13/12 (Typ.) (Tr/Td) ms
number of colors	262K/16.7M,72% NTSC	Backlight type	WLED,50K hours with LED driver
Screen Weight	1.57±0.78Kgs	be the same with	Industrial outdoor highlight
refresh rate	60Hz	touch function	touchless
signaling system	LVDS(2 ch,8-bit), Terminals, 30 pins
supply voltage	5.0V (Typ.)
maximum rated	Storage temperature: -30~80 °C Working temperature: -30~80 °C

Related Products

Brand	Model Name	Size	Resolution	Brightness	Contrast Ratio	Backlight Type	Interface	pins	Operation Temperature	Download PDF	Add Inquiry
Tianma	P2150FHF2MB00	21.5"	1920×1080	500 nits	1500:1	WLED	LVDS	30	-20~70 ° C
AUO	G215HAN01.2	21.5"	1920×1080	350 nits	1000:1	WLED	LVDS	30	0~60℃
AUO	G215HAN01.0	21.5"	1920×1080	400 nits	1000:1	WLED	LVDS	30	0~60℃
AUO	G215HVN01.4	21.5"	1920×1080	1500 nits	5000:1	WLED	LVDS	30	-20~80 ° C
AUO	G215HAN01.3	21.5"	1920×1080	250 nits	1000:1	WLED	LVDS	30	0~60℃
AUO	G215HAN01.201	21.5"	1920×1080	300 nits	1000:1	WLED	LVDS	30	-10~60 ° C
AUO	G215HVN01.3	21.5"	1920×1080	1000 nits	5000:1	WLED	LVDS	30	-20~80℃
