NEC NL8048BC24-09 is a 9.0-inch LCD panel featuring an a-Si TFT-LCD. It is equipped with a WLED backlight and an optional backlight driver board, but does not include touch function. It uses UA-SFT wide-view technology, offering viewing angles of 88/88/88/88°, ensuring no color shift or grayscale inversion when viewed from any angle. For backlight, NEC NL8048BC24-09 uses a white LED backlight with a lifespan exceeding 70,000 hours. The backlight is replaceable, and the display supports 180° rotation to accommodate various mounting orientations. It features an LVDS (1 channel, 6/8-bit) signal interface with a total of 20 pins connected via terminals, and the drive voltage is 3.3V (typ.). NEC NL8048BC24-09 is currently in mass production, ensuring a stable and long-term supply.
| Parameter | Specification |
| Brand | NEC |
| Model | NL8048BC24-09 |
| Size | 9-inch |
| Resolution | 800(RGB)×480, WVGA |
| Pixel Density | 103 PPI |
| Aspect Ratio | 15:9 |
| Display Technology | UA-SFT, Normally Black Display, a-Si TFT LCD |
| Brightness | 400 cd/m² |
| Contrast Ratio | 1000:1 |
| Viewing Angle | 88/88/88/88 |
| Response Time | 10/15 (Typ.)(Tr/Td) ms |
| Display Colors | 262K/16.7M, 60% NTSC |
| Color Temperature | 6485K |
| Interface | LVDS (1 ch, 6/8-bit) |
| Connector Type | JAE, FI-SE20P-HFE |
| Backlight Type | 7S3P WLED |
| Backlight Life | 70K |
| Built-in LED Driver Board | No |
| Touch Function | No (Custom touch screen can be matched based on your needs) |
| Operating Temperature | -20 ~ 70 °C |
| Storage Temperature | -30 ~ 80 °C |
| Active Area | 196.8(W)×118.08(H) mm |
| Visual Area | 200.2(W)×120.4(H) mm |
| Outline Dimension | 220.5×136.5×8.2 mm (H×V×D) |
| Surface Treatment | Matte, Hard Coating (3H) |
| Weight | 260/280g (Typ./Max.) |
| Vibration Resistance | 2.0G (19.6 m/s²) |
| Input Voltage (Logic) | 3.3 V (Typ.) |
| Input Current (Logic) | 360/540mA (Typ./Max.) |
| Input Voltage (Backlight) | 18.5/21.0/23.8V (Min./Typ./Max.) |
| Input Current (Backlight) | 50/55mA (Typ./Max.) |
| Replaceable Backlight | Replaceable (90LHS05) |
| Power Consumption | 4.4W (Typ.) |
| Sunlight Readability | No |
| RoHS | Yes |
♦ Industrial Sector
• Industrial Control Terminals: PLCs, Human-Machine Interfaces, industrial computer monitors, and Distributed Control System operator panels, used for real-time monitoring of production data and parameter adjustment.
• Equipment Operator Panels: Operator displays for CNC machine tools, injection molding machines, printing machinery, and textile machinery, showing equipment operating status, fault alarms, and process parameters.
• Data Acquisition and Monitoring Equipment: SCADA system display terminals, energy management system panels, and Industrial Internet of Things gateway displays, used for visualizing data from industrial sites.
• Measurement and Testing Instruments: Display modules for oscilloscopes, spectrum analyzers, environmental monitors, and non-destructive testing equipment, accurately presenting measurement curves and test results.
♦ Medical Field
• Portable Medical Devices: Portable patient monitors, electrocardiogram machines, and ultrasound diagnostic devices, providing clear data display for mobile medical scenarios.
• Bedside Monitoring Equipment: Operating displays for ward patient monitors, anesthesia machines, and ventilators, displaying patients’ vital signs in real time and supporting multi-angle viewing by medical staff.
• Medical Diagnostic Aids: Display modules for compact endoscopes, displays for pathology analysis equipment, and control panels for rehabilitation and physical therapy devices, meeting the stable display requirements of medical environments.
♦ Rail Transit Sector
• On-board Display Terminals: Metro/light rail car information screens, bus route guidance screens, and train cab monitoring displays, showing station information, operational data, and emergency notifications.
• Platform/Station Hall Equipment: Metro platform wayfinding screens, fare inquiry terminals, ticket gate displays, and passenger information service terminals, designed to meet the high-brightness and wide-viewing-angle requirements of public transportation settings.
• Signaling and Dispatch Equipment: Rail transit signaling control system panels, dispatch center monitoring terminals, and switch status monitoring displays, ensuring stable and visual operation and dispatch.
♦ More Applications
• Marine Equipment: Shipboard navigation systems, maritime radar displays, and engine room monitoring terminals, designed to withstand high-humidity and high-vibration marine environments.
• Aerospace Equipment: Small aircraft-mounted displays, ground support equipment panels, and drone ground station displays, meeting aerospace-grade reliability and anti-interference requirements.
• Office and Commercial Equipment: POS terminal displays, self-service printer panels, and office equipment control screens, providing stable commercial interactive displays.
• Special-Purpose Vehicle Equipment: Construction vehicle cab displays, fire truck/ambulance onboard terminals, and special-purpose vehicle monitoring screens, ensuring reliable information display under complex operating conditions.
1. What is the price of NEC NL8048BC24-09 LCD Panel?
A: Our pricing is flexible and adjusted based on order quantity, delivery time, and payment method. We offer tiered pricing for bulk purchases. The larger the single purchase order, the more favorable the unit price; long-term partners are also eligible for additional contract pricing. Please provide your specific requirements (quantity, delivery time), and we will issue an accurate quote as soon as possible.
2. Is NEC NL8048BC24-09 currently in stock?
A: We currently have ample stock of NEC NL8048BC24-09 and can arrange for prompt shipment. For larger orders, we will coordinate with the manufacturer based on your order volume; the standard lead time is 1–4 weeks.
3. How is product quality guaranteed?
A: We guarantee that all NEC NL8048BC24-09 units we sell are genuine, factory-sealed products from NEC. Before shipment, all products undergo rigorous optical, electrical, and environmental reliability testing to meet industrial-grade standards. We also provide a 12-month warranty; during this period, we will repair or replace the product free of charge for any quality issues resulting from non-human factors.
4. What is the warranty for NEC NL8048BC24-09?
A: Warranty Period: 12 months from the date the customer receives the product.
Warranty Coverage: Covers display defects of the panel itself, backlight failures, electrical malfunctions, and other issues not caused by human error or misuse.
Exclusions: Does not include failures caused by human error or improper operation, such as electrostatic discharge, incorrect wiring, or use in environments exceeding specified conditions.
5. Can you customize based on our equipment requirements?
A: We support a certain degree of customization:
We can provide customized resistive or capacitive touch screens as part of an integrated lamination solution; we can assist with adapting driver boards and adapter boards to enable interface conversion (e.g., LVDS to HDMI); for special backlight brightness or wide-temperature requirements, please consult us for custom solutions—specific technical feasibility and minimum order quantities will be evaluated.
6. Can the backlight of NEC NL8048BC24-09 be replaced separately?
A: Yes, the backlight can be replaced separately. NEC NL8048BC24-09 features a replaceable white LED backlight design for easy maintenance. We can provide supporting components such as backlight assemblies, driver boards, flex cables, and adapter boards, as well as repair services to help you reduce the cost of replacing the entire unit.
