White LED backlighting, surface mount terminals, 6/8-bit grayscale option available, matte finish
BOE ET104S0M-N15 is a 10.4-inch high-adaptability LCD tft display module. It features a wide temperature stability range of -20℃ to 70℃ and medical-grade display. It covers both industrial and medical scenarios: in the industrial sector, it can clearly display equipment data in complex working conditions; in the medical sector, with a 55% NTSC color gamut, it can accurately reproduce the color parameters of monitoring devices and testing equipment. Equipped with a 5.9mm thin thickness and an LVDS universal interface, it is suitable for compact installation in industrial terminals and also meets the lightweight requirements of medical equipment.
| Panel Brand | BOE | Panel Model | ET104S0M-N15 |
| Panel Size | 10.4-inch | Panel Type | a-SiTFT-LCD, LCD Module |
| Resolution | 800(RGB)x600, SVGA, 96PPI | Pixel Layout | RGB vertical stripes |
| Display Area | 211.2(W)x158.4(H) mm | Appearance Size | 236(W)x176.9(H)x5.9(D) mm |
| Viewable Area | 215.0(W)x162.0(H) mm | Surface Treatment | Haze (25%) |
| Panel Brightness | 350 cd/m² (Typ.) | Contrast | 800:1 (Typ.) (TM) |
| Visual Angle | 80/80/65/75 (Typ.) (CR≥10) | Optical Pattern | TN, normally white display, transmissive |
| Viewing Direction | 6 o'clock | Reaction Time | 30 (Typ.) (Tr+Td) ms |
| Display Color | 262K/16.7M,55% NTSC | Light Source Type | 6S4P WLED,30K hours, without driver |
| Working Frequency | 60Hz | Touch Screen | touchless |
| Weight | 300g (Max.) | Application | Industrial，Healthcare |
| Interface | LVDS(1 ch,6/8-bit), 20 pins, terminals | ||
| Driving Voltage | 3.3V (Typ.) | ||
| Environment | Operation: -20 °C to 70 ° C; Storage: -30 °C to 80 ° C | ||
•800:1 Contrast: The waveform curves of the medical monitor are clearer, assisting medical staff in quickly identifying abnormalities;
•30K Hours Backlight Lifespan: Industrial equipment can operate continuously for approximately 3-4 years, reducing the maintenance cost of screen replacements;
•3.3V Single Voltage Drive: It is compatible with centralized power supply for industrial equipment and low-power supply design for medical equipment, avoiding the complex circuit development required for multiple voltage adaptations.
1.When conducting bulk purchases, can you ensure the consistency of quality across different batches?
A: Yes, we follow a standardized production process. Each batch of products undergoes consistency tests for brightness, color temperature, and response speed. The parameter deviation between batches is ≤ 5%, ensuring uniform display effects for the batch assembly of the equipment.
2. If the equipment needs to operate for a long time, what do you do if the screen shows brightness attenuation?
A: The backlight brightness attenuation rate of this module is ≤ 10%/30K hours. If the attenuation exceeds the standard during the warranty period, it can be replaced free of charge; beyond the warranty period, we offer cost-price replacement services, and also provide guidance on brightness calibration.
3. In medical scenarios, does the screen support antibacterial treatment?
A: The basic model does not have an antibacterial coating. Customizable medical-grade antibacterial matte coating (compliant with ISO 22196 antibacterial standards) is available, which can effectively inhibit Escherichia coli, Staphylococcus aureus, etc. The sample production cycle is approximately 10 days.
4. During the transportation of industrial equipment, is the screen prone to damage?
A: Our shipping packaging uses anti-static foam + cardboard boxes for protection, and we also support customized anti-vibration packaging (suitable for long-distance transportation); if there is non-human-induced damage during transportation, it can be re-issued free of charge.
5. Can you provide a long-term supply guarantee?
A: This model is our main product, and it guarantees stable supply for at least 5 years; if it is discontinued in the future, we will notify you 12 months in advance and provide a compatible alternative model with compatible pins and dimensions to ensure that your equipment production is not affected.
6. In the use of medical equipment, will the screen generate electromagnetic interference?
A: The module passes electromagnetic compatibility tests, and the electromagnetic radiation complies with the standards for industrial/medical equipment, and will not interfere with the detection accuracy of medical equipment.
| Brand | Model Name | Size | Resolution | Brightness | Contrast Ratio | Backlight Type | Interface | pins | Operation Temperature | Download PDF | Add Inquiry |
|---|---|---|---|---|---|---|---|---|---|---|---|
| BOE | ET104S0M-N15 | 10.4" | 800×600 | 350 nits | 800:1 | WLED | LVDS | 20 | -20~70℃ | ||
| BOE | GV104X0M-N10 | 10.4" | 1024×768 | 450 nits | 1100:1 | WLED | LVDS | 30 | -30~85 ° C | ||
| BOE | BA104S01-300 | 10.4" | 800×600 | 350 nits | 800:1 | WLED | LVDS | 20 | -20~70 °C | ||
| BOE | BA104S01-200 | 10.4" | 800×600 | 300 nits | 800:1 | WLED | LVDS | 20 | -20~70 ° C | ||
| Tianma | P1040VGF1MA00 | 10.4" | 640×480 | 900 nits | 1000:1 | WLED | CMOS | 40 | -30~80 ° C | ||
| Tianma | P1040VGF1MB00 | 10.4" | 640×480 | 450 nits | 1000:1 | WLED | Parallel RGB | 40 | -30~80 ° C | ||
| Tianma | P1040SVF1MB00 | 10.4" | 800×600 | 400 nits | 1200:1 | WLED | LVDS | 20 | -20~70 ° C | ||
| Tianma | P1040SVF1ME00 | 10.4" | 800×600 | 400 nits | 1200:1 | WLED | LVDS | 20 | -20~70 ° C | ||
| Tianma | P1040XGF1MB01 | 10.4" | 1024×768 | 500 nits | 1200:1 | WLED | LVDS | 20 | -20~70 ° C | ||
| Tianma | P1040XGF1MA00 | 10.4" | 1024×768 | 1300 nits | 1000:1 | WLED | LVDS | 20 | -30~80 ° C |
