M215GWW1 R0

M215GWW1 R0

Download PDF Send Message

Basic Parameters

Panel Brand	IVO	Panel Model	M215GWW1 R0
Panel Size	21.5 inches	Panel Type	a-Si TFT-LCD, LCD module
Resolution	1920(RGB)x1080, FHD, 102PPI	Pixel Layout	RGB vertical stripe
Display Area	476.64(W)x268.11(H)mm	Appearance Size	495.6(W)x292.2(H)x20.5(D)mm
Visible Size	479.84x271.31mm(HxV)	Surface Treatment	Matt, Hard coating(3H)
Brightness(cd/m²)	1500(Typ.)	Contrast	1500:1(Typ.)[Transmission]
Optimal Angle	Full View	Optical Mode	IPS, Normally Black Display, Transmission Type
Viewing Angle	85/85/85/85(Typ.)(CR≥10)	Response Speed	35(Max.)(Tr+Td) ms
Color Quantity	16.7M, 72% NTSC	Backlight Type	WLED, 50K hours, including LED driver
Screen Weight	1.60/1.76Kgs(Typ./Max.)	Applicable To	Outdoor Brightness, Car Display
Refresh Rate	60Hz	Touch Function	No Touch
Signal System	LVDS(2 ch,8-bit), connector, 30 pins
Supply Voltage	5.0V(Typ.)
Maximum Rating	Storage temperature: -30~85℃ Operating temperature: -30~80℃; Vibration resistance: 2.9G(28.4m/s²)
